KINCO GH070 GH070E HMI

KINCO GH070 GH070E HMI

Display size - 7" TFT
Display area - 154.02(W)×85.92(H)
Resolution - 800×480 px
Display color - 16.77M true color
Visual angle - 70/70/50/70(L/R/U/D)
Contrast - 500:1
Backlight - LED
Luminance - 400cd/m²
LCD life More than 30000 hours
Touch panel 4-wire precision resistance network (surface hardness 4H)
CPU - ARM RISC 32Bit 800MHz
Memory - 128MB NAND Flash + 128MB DDR3 RAM
RTC Built-in RTC
External storage - 1USB Host + 1SD Card
Printer Port - USB Host/Serial port
Ethernet - 10/100M adaptable Ethernet interface
Program download USB Slave(Type B)/U Disk/Ethernet
Communication COM0: RS232/RS485/RS422. COM1: RS232/RS485/RS422. COM2: RS232. COM3: RS485
Serial port - isolated Built-in
