MITSUBISHI GT1155-QTBDA HMI
Screen Size: 5.7 inch
Screen Type: TFT color LCD
Communication Interface: Bus, RS-232, USB, CF Card, Optional Function Board
Graphic Standard: QVGA
Resolution: 320x240
Protection Class: IP 67f
Flash Memory: 3 MB built-in Flash Memory
Applicable Software Package: GT Works3 Version1.54G or later
Rated Input Power Supply: 24V DC
Battery Type: GT11-50BAT lithium battery
Touch Panel Type: Matrix resistive type
Panel Cut Dimensions (WxH): 153 x 121 mm
External Dimensions (WxHxD): 167 x 135 x 65 mm
Display Size (WxH): 115 x 86 mm
Display Color: 256.0
Viewing Angle: Right: 70?, Left: 70?, Up: 70?, Down: 50?
Operating Temperature: 0°C to 50°C
